2.3 Ton Double Axle Dropside Trailer 3.0m
Original price was: R56,200.00.R50,600.00Current price is: R50,600.00. incl. VAT
This double axle dropside trailer is a braked 2.3 ton 3.0 m x 1.8 m unit with 300 mm drop sides and a rear gate that fold flat for loading and lock up to hold a load. A 1.6 mm floor on twin 1 600 kg axles, wheels under the deck.
- 2500 kgGVM
- Tandem brakedAxle
- 3000 mmDeck length
- Tandem brakedBraking
Availability: 3 in stock (can be backordered)
WhatsApp about this trailerAbout this trailer
This double axle dropside trailer is a 3.0 m by 1.8 m unit plated at 2 300 kg gross, with 300 mm drop sides and a matching rear gate that hinge down flat for loading and lock up to hold a load. It is the middle ground between an open flatbed and a fully sided trailer: sides when you want them, a clear deck when you do not.
What a double axle dropside trailer gives you
Drop sides are the practical answer for mixed loads. Fold them down and the trailer loads like a flatbed from any side, by hand or by forklift; fold them up and lock them and the 300 mm sides keep sand, rubble, boxes or loose material on the deck. That flexibility is why dropsides are the default working trailer for builders, farms and hire fleets that carry a bit of everything rather than one kind of load.
Build and deck
The deck is a 1.6 mm steel-plate floor on a steel ladder-frame chassis, with the wheels under the trailer to keep the full 1.8 m width. The 300 mm drop sides and rear gate are closed with plate on a steel frame, hinged to fold flat. It runs twin 1 600 kg leaf-sprung axles, is braked, and is finished in painted 2K Duco.
Specifications
| Type | Double axle dropside trailer |
|---|---|
| GVM | 2 300 kg |
| Deck size | 3.0 m x 1.8 m |
| Sides | 300 mm drop sides and rear gate, plated |
| Floor | 1.6 mm steel plate, wheels under deck |
| Chassis | Steel ladder frame |
| Axles | Two, leaf sprung, 1 600 kg each |
| Braking | Braked |
| Finish | Painted 2K Duco |
| Tare mass | Confirmed in writing on order |
Payload, GVM and licensing
Plated at 2 300 kg gross on 1 600 kg axles and braked as standard, this trailer needs a tow vehicle with matching braked towing capacity. The supplier publishes no dependable tare, so we confirm the empty mass and payload in writing before you order. Securing a load, sides up or down, sits with the towing driver under the National Road Traffic Act.
Where it sits in the range
This is the compact dropside. The 4.0 m dropside is longer and wider, and the 6.0 m unit longer again at higher plating. If you never need sides, the matching 3.0 m flatbed is the open-deck version. Compare the range under double-axle cargo trailers.
Delivery, warranty and ordering
Delivery is free anywhere in South Africa on orders over R20 000; see our delivery page. The builder warranty, which we administer on your behalf, is under warranty, and collection from Hartswater is welcome. For a written quote, use the quote request form.
Full specification
| GVM (kg) | 2500 kg |
|---|---|
| Axle Configuration | Tandem braked |
| Braking | Tandem braked |
| Deck Length (mm) | 3000 mm |
| Suspension | Leaf spring |
| Finish | Painted 2K Duco |
| SKU | TSA-UCT-DS30-148 |
Questions about this trailer
What is a dropside trailer?
A trailer with sides that hinge down flat for loading and lock up to hold a load. It loads like a flatbed with the sides down and contains loose loads with them up.
How high are the sides?
300 mm, plated and framed in steel, on the sides and the rear gate.
Is it braked?
Yes, braked as standard at 2 300 kg GVM, so the tow vehicle needs matching braked towing capacity.
What is the payload?
It is plated at 2 300 kg on twin 1 600 kg axles. The supplier publishes no reliable tare, so we confirm empty mass and payload in writing before you order.
Do you deliver nationwide?
Yes, free on orders over R20 000, with collection from Hartswater available.
